| MECHANICAL PROPERTIES | |
|---|---|
| Cell Type | Monocrystalline-N-type |
| Component Weight | 22kg |
| Component Size | 1762x1134x30mm |
| Number of Cells | 108(6x18) |
| Cable Cross-Sectional Area | 4mm² |
| Junction Box | IP68, 3 diodes |
| Connector | MC4-EVO2 |
| Packaging Information | 36 pcs/pallet 936 pcs per 40 'HC |
| WORKING PARAMETERS | |
|---|---|
| Maximum System Voltage | 1500V (TUV) |
| Operating Temperature | -40°C~+ 85°C |
| Maximum Fuse Current Rating | 25A |
| Application Level | ClassA |
| ELECTRICAL PERFORMANCE PARAMETERS UNDER STC | ||||||
|---|---|---|---|---|---|---|
| Model | DHM54D35-435/TP | DHM54D35-440/TP | DHM54D35-445/TP | DHM54D35-450/TP | DHM54D35-455/TP | DHM54D35-460/TP |
| Maximum Power (Pmax/W) | 435 | 440 | 445 | 450 | 455 | 460 |
| Voltage at Maximum Power Point (Vmp/V) | 32.55 | 32.75 | 32.95 | 33.15 | 33.45 | 33.75 |
| Current at Maximum Power Point (Imp/A) | 13.36 | 13.44 | 13.51 | 13.57 | 13.60 | 13.63 |
| Open Circuit Voltage (Voc/V) | 37.75 | 37.95 | 38.15 | 38.35 | 38.65 | 38.95 |
| Short Circuit Current (Isc/A) | 14.08 | 14.15 | 14.21 | 14.28 | 14.35 | 14.41 |
| Component Efficiency [%] | 21.77% | 22.02% | 22.27% | 22.52% | 22.77% | 23.02% |
| Power Tolerance (W) | 0~+5 | |||||
| Temperature Coefficient of Pmax | -0.29%/°C | |||||
| Temperature Coefficient of Voc | -0.25%/°C | |||||
| Temperature Coefficient of Isc | 0.044%/°C | |||||
| Standard Test Environment | Irradiance 1000W/mi,cell temperature 25°C spectrum AM1.5 | |||||
Key Features
- N-Type Technology — High-performance N-Type solar module technology.
- Bifacial Design — Captures solar energy from both sides of the module.
- Double Glass — Features a durable double-glass module structure.
- 435–460W Power Range — Available in multiple power configurations.
- High Performance — Designed for efficient photovoltaic power generation.
Applications
- Residential Solar Systems
- Commercial & Industrial PV Projects
- Utility-Scale Solar Power Plants
- Distributed Photovoltaic Systems
- Bifacial Solar Applications
