| MECHANICAL PROPERTIES | |
|---|---|
| Cell Type | Monocrystalline-N-type |
| Component Weight | 22kg |
| Component Size | 1762x1134x30mm |
| Number of Cells | 108(6×18) |
| Cable Cross-Sectional Area | 4 mm² |
| Junction Box | IP68, 3 diodes |
| Connector | MC4-EVO2 |
| Packaging Information | 36 pcs/pallet/216Pcs per20″GP 936 pcs per 40 ’HC |
| ELECTRICAL PERFORMANCE PARAMETERS UNDER STC | ||||||
|---|---|---|---|---|---|---|
| Model | DHM54D35- 425/TP | DHM54D35- 430/TP | DHM54D35- 435/TP | DHM54D35- 440/TP | DHM54D35- 445/TP | DHM54D35- 450/TP |
| Maximum Power (Pmax) [W] | 425 | 430 | 435 | 440 | 445 | 450 |
| Voltage at Maximum Power Point (VMP) [V] | 32.15 | 32.35 | 32.55 | 32.75 | 32.95 | 33.15 |
| Current at Maximum Power Point (lmp) [A] | 13.22 | 13.29 | 13.36 | 13.44 | 13.51 | 13.57 |
| Open Circuit Voltage (Voc) [V] | 37.35 | 37.55 | 37.75 | 37.95 | 38.15 | 38.35 |
| Short Circuit Current (Isc) [A] | 13.94 | 14.01 | 14.08 | 14.15 | 14.21 | 14.28 |
| Component Efficiency [%] | 21.27% | 21.52% | 21.77% | 22.02% | 22.27% | 22.52% |
| Power Tolerance | 0～+5 | |||||
| Temperature Coefficient of Pmax | -0.350%/℃ | |||||
| Temperature Coefficient of Voc | -0.274%/℃ | |||||
| Temperature Coefficient of Isc | 0.044%/℃ | |||||
| Standard Test Environment | lrradiance 1000W/㎡,cell temperature 25°C, spectrum AM1.5 | |||||
Product Description
The DHM54D35-TP is a high-performance N-type bifacial solar module with a rated power output ranging from 425W to 450W. Combining advanced N-type solar cell technology with a durable double-glass structure, it delivers efficient and stable power generation for residential, commercial and distributed photovoltaic projects.
Its bifacial design captures direct sunlight from the front and reflected light from the rear. When installed under suitable conditions, this can increase total energy yield and improve the overall performance of the photovoltaic system.
Key Features
- Power output ranging from 425W to 450W
- Advanced N-type solar cell technology
- Bifacial power generation from the front and rear
- Durable double-glass module construction
- High conversion efficiency and energy yield
- Reliable long-term outdoor performance
- Suitable for residential and commercial installations
Typical Applications
- Residential rooftop solar systems
- Commercial rooftop PV installations
- Industrial distributed solar projects
- Solar carports and canopies
- Ground-mounted photovoltaic systems
- Agricultural photovoltaic projects
- Solar EPC and renewable energy projects
Efficient Module for Distributed PV Systems
With its practical module size, high power output and double-glass bifacial design, the DHM54D35-TP is well suited to rooftop and distributed photovoltaic projects. Its high energy yield helps customers maximize electricity generation within the available installation area while supporting dependable long-term system operation.
Contact DAHAI SOLAR for technical datasheets, detailed specifications, project quotations and customized photovoltaic solutions.
