| Model | ||
|---|---|---|
| Total Energy | 5.22kwh | |
| Usable Energy* | 4.96kWh | |
| Voltage Range | 44.8~57.6V | |
| Rated Capacity | 102Ah | |
| Nominal Voltage | 51.2V | |
| Max. Charge Voltage | 57.6V | |
| Nominal Charging Current | 50A | |
| Max. continuous charging current | 50A | |
| Nominal Discharge Current | 80A | |
| Max. continuous discharging current | 80A | |
| DOD | 95% | |
| Communication Interface | CAN/RS485/WiFi | |
| Max parallel quantity | 6 | |
| Dimension(L*W*H) | (420±2)*(161±2)*(640±2)(mm) | |
| Net Weight | (45±1)(kg) | |
| Operating Condition | Indoor | |
| When the storage time is less than 3 months, it is recommended to store at a temperature of 0-45 ℃, ≤ 90% RH, and an SOC range of 20%-50% SOC |
||
| Storage Temperature Range | When the storage time is more than 3 months, it is recommended to store at a temperature of 15-30 ℃, < 90% RH, and an SOC range of 20%-50% SOC |
|
| When the storage time exceeds 6 months,it is necessary to adiust the SOC of the battery cellto 20- 50% SOC, ≤ 90% RH, and the recommended storage temperature is 5-25 °C |
||
| High SOC(>50% SOC) storage is not allowed during storage, and full charge storage is prohibited. |
||
| Operating Temperature | Charging | 0~55 ℃ |
| Discharging | -15~55 ℃ | |
| Humidity | 15%~85%(RH)(No Condensation) | |
| Cooling Type | Natural | |
| IP Rating of Enclosure | IP20 | |
| Configuration | 16S | |
| Class of Protection | Class I | |
| Installation Method | Wall-mounted/Floor-standing | |
| Supply Connection | Fixed power cord | |
| Authentication Level | UN38.3/CE -EMC/CE-RED/CB-IEC62619 | |
Key Features
- Wall-mounted design for space-saving installation
- Designed for residential solar energy storage
- Suitable for home backup power applications
- Modular structure for convenient installation and maintenance
- Integrated battery management for safe and reliable operation
- Suitable for integration with residential photovoltaic systems
- Compact solution for home energy storage applications
Applications
The DHLV-LFP-5000 Residential ESS is suitable for home solar energy storage, residential photovoltaic systems, backup power, and other household energy management applications. It can be integrated with compatible solar inverters to create a complete residential energy storage system.
