Wall-Mounted Residential ESS DH-280T15 | Home Energy Storage System

Wall-Mounted Residential ESS -DH-280T15

Model：DH-280T15

The DH-280T15 Wall-Mounted Residential ESS is a compact energy storage solution designed for residential solar power systems and home backup applications. It stores electricity generated by photovoltaic systems and provides a reliable energy supply for household electricity needs.

With a space-saving wall-mounted design, the DH-280T15 is suitable for residential environments where efficient use of installation space is important. Its integrated energy storage and battery management design provides a practical solution for home energy management and solar power utilization.

Items	Specifications
Rated Energy(kWh)	14.336KWh
Configuration	1P16S
Nominal Voltage(V)	51.2V
Working Voltage( V)	42V~58.4V
Nominal Capacity(Ah)	280Ah
Rated Charge/ Discharge Current( A)	100A @25± 2℃
Maximum Charging Current	200A@25± 2℃
Maximum Discharging Current	200A @25± 2℃
Working Temperature	0 - 4 0 ℃( Charge) - 2 0 - 4 0 ℃( Discharge)
Humidity(%)	5~80%
Altitude Limited( m)	0-3000m
Weight(Kg)	113Kg± 3kg
Dimension(mm)	817×412×267mm
Cycle Life	6000 cycles @25℃
Cycle Life	100ACharge and discharge current 80%DOD
IP Grade	IP20
Communication Mode	CAN&RS485

Key Features

Wall-mounted design for space-saving installation
Designed for residential energy storage applications
Suitable for home solar power and backup energy systems
Compact structure for convenient installation
Integrated battery management for reliable operation
Suitable for integration with residential photovoltaic systems
Practical solution for household energy management

Applications

The DH-280T15 Residential ESS is suitable for home solar energy storage, residential photovoltaic systems, backup power, and household energy management applications. It can be integrated with compatible solar inverters to build a complete residential solar energy storage system.
