| Model | BS07-265-ES-G |
|---|---|
| Battary Parameters | |
| Battery Type | LiFePO₄ |
| Configuration | 1P264S |
| Rated Battery Voltage | DC 844.8V |
| Nominal Capacity | 314Ah |
| Battery Voltage Range | 739.2~950.4V |
| Nominal Energy | 265.267kWh |
| Usable Enargy(kWh@90%DOD) | 238.74kWh |
| Cycle Life | >8000 Cycles(@25°C,0.5C,90%DOD,70%EOL) |
| Warranty Period | 5+5 years |
| Cumulative Discharge Energy | 426.0MWh |
| PV input Parameters | |
| Input Power | 120kW |
| PV Open-circuit Voltage | DC 200~900V |
| MPPT Voltage Range | DC 200~700V |
| Start-up Voltage | 250V |
| No. of MPPT Trackers | 1 |
| Max. PV Current | 200A |
| Short-circuit Current | 60A+60A+60A+60A |
| AC (On Grid) | |
| Rated Power | 125kW |
| Output Voltage | AC 230/400V |
| Grid Frequency | 50/60Hz |
| Grlid Connection Form | 3W+N+PE |
| Power Factor | 0.99 |
| Power Factor Range | -1(leading)~1(lagging) |
| THDi | <2%(rated power) |
| AC (off-grid) | |
| Rated Power | 125kW |
| Output Voltage | AC 230/400V |
| Grid Frequency | 50/60Hz |
| AC Voltage harmonic | <3%(Linear load) |
| Isolation Transformer Parameters | |
| Voltage | AC400/400V |
| Capacity | 150kVA |
| Max. Efficiency | ≥97% |
| Short-Circuit Impedance | 4% |
| Basic Parameters | |
| Dimension (W*D*H) | 1758*1476*2135mm |
| Weight | 3350kg |
| Operating Temperature Range(°C) | -30°C~55°C(> 45°C derating) |
| Relative Humidity | 5%-90%(non-condensing) |
| IP Rating | IP54 |
| Anti-corrosion Grade | C4(Optional C5) |
| Noise | 75dB(<1m distance) |
| Altitude | ≤2000m |
| Cooling Method | Intelligent Air Cooling (Battery compartment air conditioning,electrical compartment fan) |
| Certifications | UN38.3,MSDS,IEC62619(CB),IEC63056(CB),IEC62040-1(CB),CE-EMC,IEC62477-1,IEC60529 |
Key Features
- Integrated Hybrid Solution — Combines PV, energy storage, and genset systems in one integrated solution.
- 125kW Power Capacity — Designed to meet the power requirements of various energy applications.
- 265kWh Energy Storage — Provides substantial energy storage capacity for hybrid power systems.
- Flexible Energy Integration — Supports the integration of multiple energy sources within one system.
- Integrated System Design — Simplifies system integration for different project requirements.
Applications
- Commercial Energy Storage — Suitable for commercial projects requiring integrated PV, energy storage, and genset solutions.
- Industrial Power Systems — Designed for industrial applications with multiple energy sources.
- PV Energy Storage Projects — Combines photovoltaic generation with energy storage and genset integration.
- Hybrid Power Applications — Suitable for projects requiring an integrated hybrid power solution.
