Wall-Mounted Residential ESS DH-314T16R

Wall-Mounted Residential ESS – DH-314T16R

Model：DH-314T16R

Il DH-314T16R Wall-Mounted Residential ESS is a compact energy storage solution designed for residential solar power systems, home energy storage, and backup power applications. It stores electricity generated by photovoltaic systems and makes it available for household use when needed.

With a wall-mounted design, the DH-314T16R helps save installation space while providing a practical solution for residential energy management. Its integrated battery management system supports reliable battery operation and makes the system suitable for integration with compatible solar inverters.

Items	Specifications
Rated Energy(kWh)	16.076KWh
Configuration	1 P16S
Nominal Voltage(V)	51.2V
Working Voltage( V)	45.2V~57.2V
Nominal Capacity(Ah)	31 4 Ah
Rated Charge/ Discharge Current( A)	150A @25+2℃
Maximum Charging Current	200A@25±2℃
Maximum Discharge Current	200A @25+ 2°C
Working Temperature	0-40°C(Charge)-20-40°C( Discharge)
Humidity(%)	5~80%
Altitude Limited( m)	0-3000m
Weight(Kg)	1 23Kg± 3kg
Dimension(mm)	817x41 5x267mm
Ciclo di vita	8000 cycles @25°C150ACharge and discharge current 70%DOD
IP Grade	IP20
Communication Mode	CAN&RS485

Caratteristiche principali

Wall-mounted design for efficient use of installation space
Designed for residential solar energy storage
Suitable for home backup power applications
Compact structure for convenient installation
Integrated battery management system
Suitable for integration with residential PV systems
Practical solution for home energy management

Applicazioni

Il DH-314T16R Residential ESS is suitable for residential photovoltaic systems, home solar energy storage, backup power, and household energy management. It can be combined with compatible solar inverters to build an integrated home solar energy storage system.
